DANKOFF SPECIFICATION // USA ENGINEERED
SJE PumpMaster® SPDT Float Switch
The SJE Rhombus 15PMSPDTPC (part no. 1004836) is a mechanically activated, wide-angle SPDT float switch supplied with a 15 ft water-resistant cable and pipe-mounting clamp.
Wire it for pump-down operation (normally open) or pump-up operation (normally closed).
Its adjustable pumping range is 7–36 inches.
KEY PERFORMANCE TELEMETRY
Model15PMSPDTPC
Cable Length15 FT
Running Current13 A
Pumping Range7–36 IN
- SJE PumpMaster® SPDT
- Pump-Up or Pump-Down Wiring
- 15 FT Water-Resistant Cable
Models & Details
| Model | Cable | Operation | Electrical rating | Motor rating | Mounting |
|---|---|---|---|---|---|
| 15PMSPDTPC Part no. 1004836 | 15 ft, 3-conductor 16 AWG SJOW water-resistant cable | SPDT: pump down (NO) or pump up (NC) 7–36 in adjustable range | 13 A running / 85 A starting at 120/230 VAC | Up to 1/2 HP at 120 VAC or 1 HP at 230 VAC | Pipe clamp included |
